Parameter

Range

Resolution

Notes

Voltage

0* - 60 V

0.01 V

*0 V min. w/ auxiliary power. E.g. Separately battery. Else 7.0V.

Current

0 -100 A peak

0.01 A

50 A continuous

Power

0 - 6554 W

0.1 W

Charge

0 - 65 Ah

0.001 Ah

Energy

0 - 6554 Wh

0.1 Wh

Parameter

Value

Notes

Measurement Update Period

400 mS

Signal Sampling Rate

samples/s

Data Queue Sequence time

2 seconds

In Circuit Resistance

0.001 Ohms

Operation Current

7 mA

Auxiliary Power Voltage

7.0 V - 60 V

e.g. from a separately battery

Dimensions

85mm(L) x 50mm(W) x 20mm(D)

Weight

2.3 oz.

1.7 oz. without case

Display Screen

16 character x 2 row STN LCD

Nominal Operating Conditions

0°- 50 ambient temperature, non condensing humidity

Maximum temperature must be reduced at maximum current rating
